D] Partograph

1. Definition
A tool developed by the World Health Organization (WHO) to monitor, document and manage labour. It gives a complete picture of maternal and fetal well-being and labour progress at a glance. It also provides guidelines on when labour is no longer normal.

2. Guidelines
Click this link to see an example of a WHO partograph in use and here for blank WHO partographs. See diagram left for partograph symbols



Portfolio Task
Click to access the task

Page Cont. Back Next
Partograph Symbols >
Fetal Heart

Liquor
I =
C =
M =
.
 Intact
Clear
Meconium stained
B =
.
A +
Blood Stained
Absent
Molding

O=

+=

++


+++ =

Bones are separated & sutures can be felt easily.
Bones are just touching each other.
Bones are overlapping but can be separated easily with pressure from your fingers.
Bones are overlapping but cannot be separated easily with pressure from your fingers.
Dilatation
X

Descent
O

Contractions
......
......
......
 Dots = mild contractions
< 20 secs
Diagonal Lines = Moderate contractions 20 - 40 seconds
Completely filled in = strong contractions > 40 sec
BP
